Hacking the Kodak Reels 8mm Film Digitizer (New Thread)

Forums > The Lab > Hardware

WowIndescribable
New Tinkerer
--------
Joined: Dec 17, 2025
Posts: 1
Likes: 1
Wednesday at 12:21 PM - #141
Hi, new forum user here, joined specifically for this Kodak Reels discussion. I just received my Reels digitizer, s/n H2324148BK01819. Since I have quite a few films to do that are important to me and I'm now aware of the limitations of the stock machine, I would like to try the modified firmware, and likely change the lens too. There seems to be still quite a bit of change going on by you absolutely amazing rockstar hackers in this regard (I'm deeply impressed with your creativity, generosity, and persistence). As such, at this point do ye think I should wait a bit until 'the way' has been stabilized a bit more?

Liked by SkipBurg

0dan0
Active Tinkerer
--------
Joined: Jan 13, 2025
Posts: 324
Likes: 497
Wednesday at 5:16 PM - #142
@WowIndescribable H2324148BKxxxxx is a type C, so you have no need to wait. While the firmware hacks are is still changing, but the quality improvements are slowing. If you can swap the lens, with any recent firmware, you will be good.

Liked by WowIndescribableandThePhage

0dan0
Active Tinkerer
--------
Joined: Jan 13, 2025
Posts: 324
Likes: 497
Wednesday at 9:35 PM - #143

Version 7.7 for Type A, B and C (and stock FW recovery for D users.) So nothing for Type D yet, at least now unit can be recovered if the wrong firmware is installed.

New to v7.7
- stats and controllable field are written off the video image (bottom right corner.)

- there is now an ISO Max control, supporting 100,200 & 400 ISO settings. Defaults to 100.

The code has had a lot of clean up, to it is get easier for other to start contributing. github: https://github.com/0dan0/4reels

Donations:
This project of reverse engineering a consumer product is in the grey area legally, but it shouldn't be. We own this hardware, we should be free to modify it as we want, and share those modifications without any concern. A charity that I donate to every year, Electronic Frontier Foundation (EFF), deals with customer rights like these. So if you want support projects like this one, please donate to the EFF.

You can thank me in your donation via:
https://supporters.eff.org/donate/tribute

Use this contact info.
Attachments:
FWDV280-A77-0dan0.zip (5.5 MB)
FWDV280-B77-0dan0.zip (5.5 MB)
FWDV280-C77-0dan0.zip (5.5 MB)
FWDV280-D-stock.zip (5.6 MB)
BootScreenA.png [View]
BootScreenB.png [View]
BootScreenC.png [View]
1767216551069.png [View]
1765736221544.png [View]

Liked by WowIndescribable,sdezego,ph4zand 3 others
